Beverage PET Bottled Carbonated Drink Production Line SUS304 Food Sanitary Standard
Carbonated Soft Drinks Filling Production Line
The machine could be separated to 3 modules. The height of the bottle transferring chain could be adjusted. The starwheel transfers the bottle to the rinser, filler and capper, then send out by the transferring chain. For the bottle block, bottle lack, cap lack and overload, there are protection devices. The machine meets the national food sanitary standard, highly automatic production and easy operation.
Technical Parameter:
| Item |
JB16-16-5 |
JB18-18-6 |
JB24-24-8 |
JB32-32-10 |
| Capacity |
4000bph(500ml) |
5000bph(500ml) |
8000bph(500ml) |
15000bph(500ml) |
| Rising heads |
16 |
18 |
24 |
32 |
| Filling heads |
16 |
18 |
24 |
2 |
| Capping heads |
5 |
6 |
8 |
10 |
| Bottle Diameter |
Commonly 50-110mm (can adjustable) |
| Bottle Height |
Commonly 150-340mm(can adjustable) |
| Filling pressure |
0.15-0.35Mpa |
| Rising pressure |
0.2-0.25Mpa |
| Overall size |
2130*1700*2350 |
2450*1800*2350 |
2780*2200*2350 |
3600*2650*2350 |
| Weight |
3.3t |
3.5t |
4.5t |
5.5t
|
Technical features:
- The air conveyor is directly connected with bottle-in starwheel. The bottle is transferred by neck holding.
- High speed filling line is of clamp transferring technology. Bottle shapes are more varied, and the working table inside the machine is more laconic.
- By 3-in-1 monoblock, the bottle goes through rinsing, filling and capping with little abrasion, and the transferring is stable, bottle changing is easier.
- Specially designed stainless steel bottle clamp dose not contact the thread parts of the bottle neck, avoiding the second contamination.
- The high speed line is of ring type pressure bearing hydraulic cylinder.
- High speed and large flow filling valve assures the high filling speed and exact fluid level.
- Spares contact with the liquid are all of excellent stainless steel or food level plastic. The electric system is of international brand and achieves the national food sanitary standard.
- The bottle-out starwheel is of screwdown shape. When bottle size is changed, there is no need to adjust the transferring chain’s height.
FAQ
1. How long I can get the feedback after we sent the enquiry?
We will reply you within 12 hours in working day.
2. Are you a factory or trading company?
We are a factory,professional packing machinery manufacturers with about years of
experience.
3. How long is the warranty of your equipment?
1 year warranty after receipt check upon delivery.And we will comprehensively provide
you all kinds of technical support services in after-sale!
4. What is packing of this machine similar with other supplier?
Machine will be packed by standard wooden case.It is suiable for shipment.After you
receive machine,you only need to open wooden case to pick up machine.
5. Why your machine similar with other supplier?,
We are a overseas-funded ebterprise.We are manufacturer and had been in this industyr for more than 15years,with more than 10 years export experience.We design machines by ourselves with advanced technology.Appearance just a part of machine,Service and quality is more important than it.
7. I'm new in our industry, but i'm planning to setup a factory, What can i do?
We can suggest customer the most suitable machine according to their formula, Raw material.
Manufacturing-Installation-Training-Maintenance-Technical Supprt. We can introduce you supplier of raw material, bottles,labes etc.We could take you to our customer´s factory to learn how they produce. We could sustomize machines according to you real need,We could send our engineer to your factory to install machines and train your worker of Operationand maintenace.Any more requests.Just let us know.
