| NO. |
NAME |
MAIN TECHNOLOGY PARAMETER |
| 1 |
MILK RECEIVESTORAGEAND CREAM SEPARETOR UNIT |
| 2 |
electron pound scale |
maximum weighing 500KG |
| 3 |
milk weighing tank |
made of SUS stainless steal,single layer,product feeded in through 40 mesh filter net,CIP cleaning ball |
| 4 |
milk acceptor |
SUS304 stainless steel,single layer,CIP cleaning ball |
| 5 |
milk pump |
SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished |
| 6 |
twin piping filter |
SUS304 stainless steel,two pipe,Stainless Steal Filter Element 100 Mesh |
| 7 |
dish separator |
auto residue discharge |
| 8 |
chiling tank |
SUS304 stainless steel,alveolate jacket,attached with compressor |
| 9 |
milk pump |
SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished |
| 10 |
PREPARING UNIT |
| 11 |
blending tank |
SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet |
| 12 |
milk pump |
SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished |
| 13 |
mini set of plate-type heat exchanger |
SUS304 stainless steel,two stages, |
| 14 |
high speed emulsification tank |
SUS304 stainless steel,heat insulated,bottom high speed emulsifier,digital readout thermometer,supporters with adjustable feet |
| 15 |
milk pump |
SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished |
| 16 |
twin piping filter |
SUS304 stainless steel,two pipe,Stainless Steal Filter Element 100 Mesh |
| 17 |
Sterilizing,homogenizing unit |
| 18 |
UHT sterilizer |
tub-type,sterilzing temperature 137 C,holding time 4S,full automatic control |
| 19 |
high pressure homogenizer |
40MPa,(starting box included) |
| 20 |
temperature holding |
SUS304,holding 300S |
| 21 |
distributing plate |
SUS304,3 holes |
| 22 |
Cheesebutter processing unit |
| 23 |
bufferying tank |
SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet |
| 24 |
milk pump |
SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished |
| 25 |
Cream seperator |
|
| 26 |
bufferying container |
SUS304,with cover |
| 27 |
milk pump |
SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished |
| 28 |
butter-churner |
SUS304,stepless timing |
| 29 |
cheese vat |
SUS304,with heating jacket and insising device |
| 30 |
pressor |
SUS304,6 heads |
| 31 |
mould |
SUS304,10L,with cover |
| 32 |
yogurt fermentation unit |
| 33 |
fermentation tank |
SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet |
| 34 |
rotary pump |
SUS304 stainless steel,Hard Alloy Mechanical Seal,manual stepless shift |
| 35 |
plate cooler |
SUS304,single stage,milk discharge at 4C |
| 36 |
rotary pump |
SUS304 stainless steel,Hard Alloy Mechanical Seal,manual stepless shift |
| 37 |
filling unit |
| 38 |
higher position tank |
SUS304 stainless steel,heat insulated,top off- center votical agitator,conical head,airtight manhole, breather valve,digital readout thermometer,anti-eddy baffle,supporters with adjustable feet |
| 39 |
pasteurized milk filling machine |
|
| 40 |
yogurt filling machine |
|
| 41 |
CIP system |
| 42 |
semi-auto CIP system |
outer coat of SUS304 stainless steel material,inner shell of SUS316,single cleaning way,Concentrated acid/alcali tank adding system based on US technology, 100L×2 acid/alcali Concentrate tanks |
| 43 |
CIP return pump |
SUS304 stainless steel,pump lift 24M,Hard Alloy Mechanical Seal,Inner Shell Bright-Polished |
| 44 |
installation part |
whole milk processing line installation and commissioning |
